Description

Sansui G-8000 Pure Power DC Stereo Receiver

Description:
The Sansui G-8000 Receiver is a highly acclaimed component, offering superior sound performance. Featuring a sophisticated tone control circuit with four switchable distortion characteristics, it allows for unmatched audio control and flexibility. With a powerful 120 watts per channel, the G-8000 is the perfect choice for the audio enthusiast.

Specifications:
Tuning range: FM, MW
Power output: 120 watts per channel into 8Ω (stereo)
Frequency response: 5Hz to 50kHz
Total harmonic distortion: 0.03%
Damping factor: 60
Input sensitivity: 6mV (mic), 2.5mV (MM), 150mV (DIN), 150mV (line)
Signal to noise ratio: 78dB (MM), 95dB (line)
Channel separation: 60dB (MM), 70dB (line)
Output: 150mV (line), 43mV (DIN), 1V (Pre out)
Speaker load impedance: 4Ω to 8Ω
Semiconductors: 104 x transistors, 70 x diodes, 11 x FET, 7 x IC, 10 x LED
Dimensions: 560 x 201 x 475mm
Weight: 24.6kg
Year: 1978-1980
Serial No: 818030692

Description of Works:
Replaced all electrolytic with Nichicon FG, FW, Vishay & Jamicon capacitors.
Replaced and upgraded polyester with WIMA capactors.
Inspect and replaced several small signal transistors.
Inspect output transistors.
Inspect and re-soldered all PCB's.
Adjust bias and DC offset.
New Illumination globes.
Dismantled, cleaned & deoxit potentiometers and switches.
New speaker banana binding posts.
Cleaned & detailed unit.
New 240vac power lead.

Warranty: 12 months

RV HIFI says:
In the 1970s, Sansui made some remarkable receivers, including the G-series, whose models boasted 16 to 300 watts of power per channel. On offer here is the G-8000, providing 120 watts per channel rms. It is in excellent condition, with hardly noticable scuffs, most have been polished out. The circuitry has been outfitted with new high-end capacitors and fully reviewed and serviced. Audio quality is superbly defined, clear, dynamic, and potent; a product of the golden era of Hi-Fi where design and craftsmanship were unmatched.


 Due to the weight and cubic dimensions of this item, we request that you contact us on 0419700769 or by email for a quote on shipping to your location.
