NAIM ND5 XS2 Network Music Streamer

NAIM ND5 XS2 Network Music Streamer

The ND5 XS 2 uses our innovative new streaming platform with an expanded feature set. High-res UPnP™ streaming, AirPlay, AirPlay 2, Chromecast built-in, Bluetooth (apt X HD), Spotify Connect, TIDAL, Qobuz, Roon compatibility, internet radio and multiroom streaming – alongside digital and USB inputs for conventional connections – make this versatile player the ideal partner for one of our integrated amplifiers.

Carefully selected and matched parts, an oversized toroidal transformer, decoupled PCB boards: the ND5 XS 2 benefits from classic Naim engineering and fastidious attention to detail to ensure that it delivers natural, engaging sound quality from all sources.

• UPnP-enabled to allow streaming of audio files at up to 32bit/384kHz resolution from Naim Audio hard disk servers, network-attached storage (NAS) devices or any home computer
• Supports a broad range of music formats: WAV, FLAC, DSD, Apple Lossless, AIFF, AAC, Windows Media-formatted files, M4A and MP3. Gapless playback on all file formats
• Four 24bit/192kHz capable digital inputs (S/PDIF) to support optimum connection to external sources
• Built-in Chromecast allows you to stream from hundreds of supported smartphone or tablet apps (192kHz)
• Apple AirPlay – stream music from your iOS device or from iTunes and Apple Music
• Spotify Connect built-in to stream millions of songs from the world’s most popular streaming service
• Front-panel USB port for replay of MP3 player and USB-stored audio (1.6A charge)
• vTuner 5* full-service internet radio
• Multiroom & Party Mode compatible
• iOS and Android Naim Audio app for intuitive control
• Bluetooth connectivity with aptX codec for quality audio playback
• Thanks to RC5 system integration, you can control compatible amplifiers that are connected to your network player directly from the Naim app on a phone or tablet
• Roon ready – turning your music collection into a beautifully laid out catalogue

Specifications:
Audio Inputs
Streaming: Chromecast built-in, Apple AirPlay, TIDAL, Spotify® Connect, Bluetooth (AptX HD), Internet Radio, UPnP™ (hi-res streaming), Roon Ready
USB
2 x USB Type A socket (front and rear – 1.6A charge)
Digital (S/PDIF)
2 x optical TOSLink (up to 24bit/96kHz)
1 x coaxial RCA (up to 24bit/192kHz, DoP 64Fs)
1 x coaxial BNC (up to 24bit/192kHz, DoP 64Fs)
Audio Outputs
Analogue:
1 x RCA pair
1 x 5-pin DIN
Connectivity
Multi-room
Party Mode Streaming: Sync up to six Naim products and control via the Naim app
Updates
Update your system wirelessly via the Naim app
Network
Ethernet (10/100Mbps), WiFi (802.11 b/g/n/ac with external antennae)
Formats
Internet Radio Formats:  Windows Media-formatted content, MP3, ACC, OGG Vorbis streams and MMS
Internet Radio Provider:  vTuner premium 5*
Audio Formats
WAV – up to 32bits/384kHz
FLAC and AIFF – up to 24bit/384kHz
ALAC (Apple Lossless) – up to 24bit/384kHz
MP3 – up to 48kHz, 320kbit (16 bit)
AAC – up to 48kHz, 320kbit (16 bit)
OGG and WMA – up to 48kHz (16 bit)
DSD – 64 and 128Fs
M4A – up to 48kHz, 320kbit (16 bit)
Note: Gapless playback supported on all formats
Dimensions
W432 x D320 x H66 mm
Weight
6.6kg
Power
Mains Supply:  100V, 115V or 230V; 50 or 60Hz
Power Consumption
Typical use: 11W
Network standby mode: <2W
Deep sleep: <0.5W

Serial No. 472042
