ALTEC LANSING Model Five Loudspeakers

ALTEC LANSING Model Five Loudspeakers

SPECIFICATIONS:
Woofer : 1x 12"
Tweeter : 2x 4"
Nominal impedance : 8 Ohm
Crossover : 1.5Khz
Enclosure : Vented
Sensitivity : 91.5dB SPL (4ft @ 1W, 8 Ohm input, 500Hz, 3Khz pink noise)
Frequency response : 45Hz - 20Khz
Dispersion : 90deg @ -6dB vertical, 120deg @ -6dB horizontal (4ft @ 800Hz, 8Khz pink noise)
Long-term power : 45W
Operational power : 12W...150W
Long-term acoustic output : 108dB at 45W
Dimensions : H648 x W368 x D305mm
Weight : 14.5kgs each
Serial No: 17250
Year: 1975 - 1978

Description of Works:
Replaced all capacitors in crossover network.
Inspected and checked all speaker drivers.
Sand-down enclosures, repaired, stained and sealed with oil based polyurethane.
New gaskets on woofers.

Warranty: 3 months

RV HIFI Says:
The Model Five utilizes a novel technique, it employs three drivers in a two-way system, a single bass driver, but two drivers for high frequencies instead of one. The result is increased midband sensitivity, 91.5dB SPL @ 4 feet, system power capacity is increased over single driver designs. The drivers are positioned on the baffle in a manner that produces uniform dispersion and an accurate stereo image whether the cabinet is placed vertically or horizontally.

Due to the weight and cubic dimensions of this item, we request that you contact us on 0419700769 for a quote on shipping to your location.
